The range of our brass alloys

It is a copper-zinc alloy whose copper content can vary from 57 to 63% and zinc and other elements are added to obtain specific properties. Over the years, Almag has collected one of the widest ranges of alloys in the industry. Dozens of research projects are still on-going today, making our offer more complete every day.


Filter:
LEGA Cu Pb Sn Fe Ni Al Mn As Si P Zn Other Designation and Ref. Standard Notes Tech. datasheet
36Pb3 Cu: Min: 60,00
| Max: 62,00
Pb: Min: 2,50
| Max: 3,50
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW603N / CuZn36Pb3
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard alloy in the USA for machining with chip removal. Included in 4MS Positive List. dwl
37P Cu: Min: 61,00
| Max: 65,00
Pb: Min: -
| Max: 0,25
Sn: Min: -
| Max: -
Fe: Min: -
| Max: 0,35
Ni: Min: -
| Max: -
Al: Min: -
| Max: -
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: 0,05
| Max: 0,20
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: C27451 / CuZn37P
Ref. Standard:
_
Notes: Dezincification resistant alloy with low lead content. Compliant to USA market. dwl
39Pb3 Cu: Min: 57,00
| Max: 59,00
Pb: Min: 2,50
| Max: 3,50
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW614N / CuZn39Pb3
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard alloy for machining with chip removal. It is included in 4MS Positive List. dwl
39Pb3-HS Cu: Min: 57,00
| Max: 59,00
Pb: Min: 2,50
| Max: 3,50
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW614N / CuZn39Pb3
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard alloy for High Speed machining with chip removal. Recommended for round brass rods.Included in 4MS Positive List. dwl
60/40 Pb Cu: Min: 59,00
| Max: 61,50
Pb: Min: -
| Max: 0,20
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,20
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW509L / CuZn40
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: High copper and reduced lead alloy. Included in 4MS Postive List. dwl dwl
607N Cu: Min: 60,00
| Max: 61,00
Pb: Min: 0,80
| Max: 1,60
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,20
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW607N / CuZn38Pb1
Ref. Standard:
DM 174 06/04/2004
Notes: Medium-copper alloy with reduced lead. dwl
610 Cu: Min: 59,00
| Max: 60,50
Pb: Min: 0,20
| Max: 0,80
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,20
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW610N / CuZn39Pb0,5
Ref. Standard:
DM 174 06/04/2004
Notes: Leaded Muntz Metal. dwl dwl
708R Cu: Min: 66,00
| Max: 70,00
Pb: Min: -
| Max: 0,80
Sn: Min: -
| Max: -
Fe: Min: -
| Max: 0,40
Ni: Min: -
| Max: 0,50
Al: Min: -
| Max: -
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: 0,70
| Max: 1,30
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW708R / CuZn31Si
Ref. Standard:
-
Notes: Special alloy with high mechanical resistance and  wear resistance. High-copper alloy. dwl
713R Cu: Min: 57,00
| Max: 59,00
Pb: Min: 0,20
| Max: 0,80
Sn: Min: -
| Max: 0,40
Fe: Min: -
| Max: 1,00
Ni: Min: -
| Max: 1,00
Al: Min: 1,30
| Max: 2,30
Mn: Min: 1,50
| Max: 3,00
As: Min: -
| Max: -
Si: Min: 0,30
| Max: 1,30
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW713R / CuZn37Mn3AI2PbSi
Ref. Standard:
-
Notes: Special alloy with high mechanical resistance and wear resistance. dwl
C363 Cu: Min: 61,00
| Max: 63,00
Pb: Min: 0,25
| Max: 0,70
Sn: Min: -
| Max: -
Fe: Min: -
| Max: 0,15
Ni: Min: -
| Max: -
Al: Min: -
| Max: -
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: 0,04
| Max: 0,15
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: C36300
Ref. Standard:
-
Notes: Antidezincifying alloy with low lead content and without arsenic. dwl
C67300 Cu: Min: 59,00
| Max: 63,00
Pb: Min: 0,40
| Max: 3,00
Sn: Min: -
| Max: -
Fe: Min: -
| Max: 0,50
Ni: Min: -
| Max: 0,25
Al: Min: -
| Max: 0,25
Mn: Min: 2,00
| Max: 3,50
As: Min: -
| Max: -
Si: Min: 0,50
| Max: 1,50
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: C67300
Ref. Standard:
-
Notes: Special anti-friction and wear-resistant alloy. dwl
CZ-LL Cu: Min: 61,50
| Max: 63,50
Pb: Min: -
| Max: 0,20
Sn: Min: -
| Max: 0,10
Fe: Min: -
| Max: 0,10
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: 0,02
| Max: 0,15
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW511L / CuZn38As
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Anti-dezincification alloy for the USA markek. Certified NSF372 and included in 4MS Positive List. dwl dwl
CZ-NL Cu: Min: 61,50
| Max: 63,50
Pb: Min: -
| Max: 0,10
Sn: Min: -
| Max: 0,10
Fe: Min: -
| Max: 0,10
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: 0,02
| Max: 0,15
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW511L / CuZn38As
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard anti-dezincification alloy lead-free. It is included in 4MS Positive List. dwl dwl
CZ129 Cu: Min: 59,00
| Max: 60,00
Pb: Min: 0,80
| Max: 1,60
Sn: Min: -
| Max: -
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW611N / CuZn39Pb1
Ref. Standard:
-
Notes: Lead alloy for hot forging. dwl
CZ132 Cu: Min: 61,00
| Max: 63,00
Pb: Min: 1,70
| Max: 2,80
Sn: Min: -
| Max: 0,10
Fe: Min: -
| Max: 0,10
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: 0,10
As: Min: 0,02
| Max: 0,15
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW602N / CuZn36Pb2As
Ref. Standard:
DM 174 06/04/2004
Notes: Standard Anti-dezincification alloy. dwl dwl
CZA25 Cu: Min: 62,00
| Max: 64,00
Pb: Min: 1,20
| Max: 1,60
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: 0,50
| Max: 0,70
Mn: Min: -
| Max: 0,10
As: Min: 0,02
| Max: 0,15
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW625N / CuZn35Pb1,5AIAs
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard anti-dezincification alloy. Included in 4MS Positive List. dwl dwl
CZA26 Cu: Min: 64,00
| Max: 66,00
Pb: Min: 1,20
| Max: 1,70
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: 0,80
| Max: 1,00
Mn: Min: -
| Max: 0,10
As: Min: 0,02
| Max: 0,15
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW626N / CuZn33Pb1,5AIAs
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard anti-dezincification alloy. Included in 4MS Positive List. dwl dwl
EURO Cu: Min: 57,00
| Max: 59,00
Pb: Min: 1,60
| Max: 2,20
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,10
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW617N / CuZn40Pb2
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard alloy with high workability. Included in 4MS Positive List. dwl dwl
EURO-HS Cu: Min: 57,00
| Max: 59,00
Pb: Min: 1,60
| Max: 2,20
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,10
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW617N / CuZn40Pb2
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: High workability alloy and reduced lead content. It is included in the 4MS Positive List. dwl
FAB Cu: Min: 57,00
| Max: 59,00
Pb: Min: 2,20
| Max: 2,50
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW617N / CuZn40Pb2
Ref. Standard:
DM 174 06/04/2004
Notes: Standard alloy for hot stamping with lead > 2,2%. dwl
GSM Cu: Min: 59,00
| Max: 60,00
Pb: Min: 1,60
| Max: 2,20
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,10
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW612N / CuZn39Pb2
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard high copper content alloy for free machining. Included in 4MS Positive List. dwl
LFB Cu: Min: 57,00
| Max: 59,00
Pb: Min: -
| Max: 0,20
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW510L / CuZn42
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Alloy with low lead content. Certified NSF372 for USA market. Included in 4MS Positive List. dwl dwl
MSPB2 Cu: Min: 57,00
| Max: 59,00
Pb: Min: 1,60
| Max: 2,00
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,10
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW617N / CuZn40Pb2
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard alloy for hot forging with lead < 2%. Included in 4MS Positive List. dwl dwl
NB (Navale - Naval) Cu: Min: 59,00
| Max: 61,00
Pb: Min: -
| Max: 0,20
Sn: Min: 0,50
| Max: 1,00
Fe: Min: -
| Max: 0,10
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: -
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW719R / CuZn39Sn1
Ref. Standard:
_
Notes: Special alloy with high mechanical and corrosion resistance. Classic material for naval use. dwl
NLB Cu: Min: 57,00
| Max: 59,00
Pb: Min: -
| Max: 0,10
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW510L / CuZn42 DIN 50930-6
Ref. Standard:
DM 174 06/04/2004
Notes: Lead-free alloy with optimized workability. dwl
OT60/40 Cu: Min: 59,00
| Max: 61,50
Pb: Min: -
| Max: 0,05
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,20
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW509L / CuZn40
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: High copper content and low lead content alloy, also known as Muntz metal. Compliant to USA market. Included in 4MS Positive List. dwl dwl
OT/63 Cu: Min: 62,00
| Max: 64,00
Pb: Min: -
| Max: 0,1
Sn: Min: -
| Max: 0,10
Fe: Min: -
| Max: 0,10
Ni: Min: -
| Max: 0,20
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,1
Designation: CW508L / CuZn37
Ref. Standard:
-
Notes: High cold deformability alloy. Included in 4MS Positive List. dwl
OTS D Cu: Min: 57,00
| Max: 59,00
Pb: Min: 0,20
| Max: 0,80
Sn: Min: -
| Max: 0,50
Fe: Min: -
| Max: 0,50
Ni: Min: -
| Max: 0,50
Al: Min: 0,30
| Max: 1,30
Mn: Min: 0,80
| Max: 1,80
As: Min: -
| Max: -
Si: Min: 0,20
| Max: 0,80
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW718R / CuZn39Mn1AlPbSi
Ref. Standard:
-
Notes: Special alloy with high mechanical resistance and  wear resistance. dwl
PS Cu: Min: 59,00
| Max: 60,00
Pb: Min: 1,60
| Max: 2,20
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,10
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: 0,03
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW612N / CuZn39Pb2
Ref. Standard:
DIN 50930-6 / DM 174 06/04/2004
Notes: Standard high copper content alloy. Included in 4MS Positive List. dwl dwl
QQB Cu: Min: 60,00
| Max: 61,00
Pb: Min: 1,60
| Max: 2,50
Sn: Min: -
| Max: 0,20
Fe: Min: -
| Max: 0,20
Ni: Min: -
| Max: 0,30
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: -
As: Min: -
| Max: -
Si: Min: -
| Max: -
P: Min: -
| Max: -
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW608N / CuZn38Pb2
Ref. Standard:
DM 174 06/04/2004
Notes: Standard high copper content alloy for chip removal. dwl
SYD Cu: Min: 64,00
| Max: 67,00
Pb: Min: 0,40
| Max: 0,60
Sn: Min: -
| Max: 0,30
Fe: Min: -
| Max: 0,30
Ni: Min: -
| Max: 0,20
Al: Min: 0,10
| Max: 0,40
Mn: Min: -
| Max: 0,10
As: Min: 0,05
| Max: 0,08
Si: Min: 0,10
| Max: 0,30
P: Min: -
| Max: 0,02
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW725R / CuZn33Pb1AISiAs
Ref. Standard:
DM 174 06/04/2004
Notes: Anti-dezincification alloy with low lead release. Included in the 4MS Positive List. dwl dwl
SIBRASS Cu: Min: 75,0
| Max: 77,0
Pb: Min: -
| Max: 0,1
Sn: Min: -
| Max: 0,3
Fe: Min: -
| Max: 0,3
Ni: Min: -
| Max: 0,2
Al: Min: -
| Max: 0,05
Mn: Min: -
| Max: 0,05
As: Min: -
| Max: -
Si: Min: 2,7
| Max: 3,5
P: Min: 0,02
| Max: 0,10
Zn: Min: Diff.
| Max: -
Other: Min: -
| Max: 0,2
Designation: CW724R / CuZn21Si3P
Ref. Standard:
-
Notes: Antidezincyfing alloy with high mechanical properties. dwl dwl
Characteristics

Among all the possible alloys of copper and zinc, brasses occupy a marginal role in the phase diagram. More precisely, copper alloys of technological interest have copper content ranging from 57% to 70%. The α phase has good cold workability while the β phase has good hot workability.

CONTINUE
caratteristiche leghe rame e zinco
Proprietá dell’ottone
Properties of brass

Brass is commonly perceived as an alloy for architectural uses, due to its characteristic colour and resemblance to gold. But it has more other properties: recyclability, affordability and environmental sustainability are fundamental factors in various fields of application.

CONTINUE
